VOE938073 Hose assembly for Volvo Excavator Parts

VOE938073 Hose assembly for Volvo Excavator Parts

volvo-voe938073-on-sale

View

View

VOE938073 Hose assembly for Volvo Excavator Parts

Interview

Select the number of specifications

Please check the product information you want!

Product Detail

Volvo Hose assembly Part NO. VOE938073

Part Name: VOE938073 Hose assembly
KDSORT: 250, 240
UE: U
ANT1: 1
Hose Recipe Asmoverall Length MM: 1425
Hose Recipe Asmoverall Length Inch: 56.10
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 3
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Pilot
Hose Part Hose Size DN: 6
Hose Part Hose Size Inch: 1/4"
Hose Part Hose Dash: -04
Hose Part Hose Pressure Class MPA: 15.0
Hose Part Hose Pressure Class PSI: 2175
Hose Part Hose Pressure Class BAR: 150
Hose Part Hose Standard ISO: Volvo 100
Hose Part Hose Standard SAE: Volvo 100
Hose Part Hose Standard EN: Volvo 100
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided one layer
Hose Part Hose Remark: Extreme lightness
Hose Part Hose Outer Diameter MM: 12
Hose Part Hose Outer Diameter INCH: 0.47
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20133/916/700, 20714/924/2300, 20712/924/2400, 20134/916/700
Looking for Part NO.VOE938073?
We offer Doosan / Komatsu / SUMITOMO / YANMAR / Deutz / Kubota aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
VOE938073 for Volvo Working hydraulic, slope and rotator on upper frame(1075475 assembly)
Volvo VOE938073 Pilot suitable for 1075475 Working hydraulic, slope and rotator on upper frame assembly.
Volvo VOE938073(c.1075475) Pilot
Ref: 1075475 / 13 / 1
VOE8295299 / U / PROPORTIONAL CONTROL Leak-off line for slope-rotator on basic machine
VOE8295300 / U / PROPORTIONAL CONTROL Leak-off line for slope-rotator on basic machine
VOE8293022 / U / PROPORTIONAL CONTROL Leak-off line for slope-rotator on basic machine
VOE8293021 / U / ON/OFF Leak-off line for slope-rotator on basic machine
20712/924/2400, 20714/924/2300
VOE938073 for Volvo Working hydraulic, dozer blade(1059863 assembly)
Volvo VOE938073 Hose assembly suitable for 1059863 Working hydraulic, dozer blade assembly.
Volvo VOE938073(c.1059863) Pilot
Ref: 1059863 / 10 / 1
VOE11839485 / U Orientable Blade
VOE11839424 / U Orientable Blade
20134/916/700, 20133/916/700
Heavy machine parts supply CUMMINS / Doosan / Kubota / KATO / Komatsu / MITSUBISHI aftermarket parts. MOQ 1 pcs is available! VOLVO Part NO.VOE938073 is on sale now!
Part NO. VOE938073 for Volvo EC250E(S/N 310001-, 320001-)
EXCAVATOR VOLVO EC250E
BASIC MACHINE
Product number 8294127, Serial number 310001-, 320001-
CAB
Product number 8292998
Product number 8294134
Product number 8295278
Product number 8295279
Product number 8302184
Product number 8302185
Product number 8302186
Product number 8302187
ENGINE
Replacement version 17211950
Replacement version 17211952
Replacement version 17480998, D8J T4F
Replacement version 17507022, D8J T4F
Replacement version 17668815, D8 STAGE V
Part NO. VOE938073 for Volvo EC35C
EXCAVATOR VOLVO EC35C
BASIC MACHINE
PROD NO 11839908, S/N 3538 -
ENGINE
Part No. 11806938, S/N - 4104
Part No. 11808572, S/N 4105 -
Part NO. VOE938073 for Volvo EC300E(S/N 310001-)
EXCAVATOR VOLVO EC300E
BASIC MACHINE
Product number 8291752, Serial number 310001-
CAB
Product number 8292998
Product number 8294134
Product number 8295278
Product number 8295279
Product number 8295391
Product number 8302184
Product number 8302185
Product number 8302186
Product number 8302187
Product number 8302183
ENGINE
Product number 17211954
Product number 17211955
Product number 17480999, D8J T4F
Product number 17507024, D8J T4F
Product number 17668831, D8 STAGE V
Part NO. VOE938073 for Volvo ECR48C
EXCAVATOR VOLVO ECR48C
BASIC MACHINE
PROD NO. 11839909, S/N 4838 -
ENGINE
Part No. 11806938, S/N - 5175
Part No. 11808572, S/N 5176 -
We have our own production/R&D factory, high quality and low price are our advantages.
With more than 10 years of machinery industry experience, we have received praise from all over the world (customer / reseller / manufacturers / distributors).
Original VOE938073 included regular invoice.
Used/Second hand VOE938073 provide 3-12 months quality guarantee .
All Taxes included, no more hidden fee.
Choose us, get permanent online support, our Golden Engineers are ready.
