Hose assembly VOE15800373 for Volvo excavator EC300D(S/N 21/23/231001-/25/ 26/27/28000-) excavator
Part Name: VOE15800373 Hose assembly
KDSORT: 240, 380, 550, 250, 146, 290, 270
UE: U
ANT1: 1
ANT2: 1
GLB_ANM1: S/N 210552-/270227-
GLB_ANM2: S/N 280057-/230111-
Hose Recipe Asmoverall Length MM: 1750
Hose Recipe Asmoverall Length Inch: 68.90
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Rockmaster/4SP
Hose Part Hose Size DN: 12
Hose Part Hose Size Inch: 1/2"
Hose Part Hose Dash: -08
Hose Part Hose Pressure Class MPA: 42.0
Hose Part Hose Pressure Class PSI: 6090
Hose Part Hose Pressure Class BAR: 420
Hose Part Hose Standard ISO: ISO 3862 4SP
Hose Part Hose Standard SAE: Volvo 102
Hose Part Hose Standard EN: EN 856 4SP
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire spiralled four layer
Hose Part Hose Remark: Abrasion, weather and heat resistance
Hose Part Hose Outer Diameter MM: 25
Hose Part Hose Outer Diameter INCH: 0.98
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20612/911/740, 20615/911/740, 20725/924/2410, 20229/916/10600, 20719/916/10400, 20718/916/10450, 20725/924/2400, 20629/924/1050
Looking for Part NO.VOE15800373?
We supply SAMSUNG / ISUZU / CASE / MITSUBISHI / KATO / CUMMINS aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo VOE15800373 Hose assembly suitable for 1030048 Working hydraulic, slope and rotator on upper frame assembly.
Volvo VOE15800373(c.1030048) Hose assembly
Ref: 1030048 / / 2
VOE8293107 / U / ON/OF, 40 LPM Leak-off line for slope-rotator on basic machine
VOE8293108 / U / ON/OF, 60 LPM Leak-off line for slope-rotator on basic machine
VOE8292063 / U / PROPORTIONAL 60LPM Leak-off line for slope-rotator on basic machine
20629/924/1050
Volvo VOE15800373 Rockmaster/4SP suitable for 1049812 Working hydraulic, slope and rotator on upper frame assembly.
Volvo VOE15800373(c.1049812) Rockmaster/4SP
Ref: 1049812 / 6 / 1
VOE8296461 / U / PROPORTIONAL CONTROL Leak-off line for slope-rotator on basic machine
VOE8296459 / U / ON/OFF, 60LPM Leak-off line for slope-rotator on basic machine
VOE8294898 / U / ON/OFF, 40LPM Leak-off line for slope-rotator on basic machine
VOE8296460 / U / PROPORTIONAL CONTROL Leak-off line for slope-rotator on basic machine
20725/924/2410, 20725/924/2400
Volvo VOE15800373 Hose assembly suitable for 1077914 Working hydraulics, base boom modular joint assembly.
Volvo VOE15800373(c.1077914) Hose assembly
Ref: 1077914 / 15 / 2
VOE8296970 / U / BASE Boom
VOE8302312 / U / EXTENSION BOOM Long boom
20718/916/10450
Volvo VOE15800373 Hose assembly suitable for 1067053 Working hydraulics, demolition boom assembly.
Volvo VOE15800373(c.1067053) Rockmaster/4SP
Ref: 1067053 / 12,17 / 2
VOE8293494 / U / DEMOLITION Boom
20229/916/10600
Volvo VOE15800373 Rockmaster/4SP suitable for 1078393 Working hydraulics, base boom small piping assembly.
Volvo VOE15800373(c.1078393) Hose assembly
Ref: 1078393 / 19 / 1
VOE8297386 / U Boom
VOE8299626 / U / BASE BOOM WITH DEMOLITION EXTENSION Boom
20719/916/10400
Heavy machine parts supply Hitachi / ISUZU / Komatsu / MITSUBISHI / HYUNDAI / CASE spare parts. MOQ 1 pcs is available! VOLVO Part NO.VOE15800373 is on sale now!
Part VOE15800373 suitable for:
VOE8292193 / U / HYDRAULIC FAN W X3 Cooling system
VOE8293158 / U / HYDRAULIC FAN W X3 Cooling system
VOE8291934 / U / HYDRAULIC FAN W X3 Cooling system
VOE8292873 / U / HYDRAULIC FAN W X3 Cooling system
Part NO. VOE15800373 for Volvo EC220D(S/N 21/22/23/231/24/245 /26/27/28)
EXCAVATOR VOLVO EC220D
BASIC MACHINE
PROD NO. 8289742, S/N 210001-210889, 220001-221458, 230001-230418, 231001-, 240001-, 245001-, 260001-260111, 270001-, 280001-
SUB BASIC MACHINE
PROD NO. 8292707, S/N 210001-210889, 220001-221458
PROD NO. 8292038, S/N 230001-230418, 231001-, 240001-, 245001-, 260001-260111, 270001-, 280001-
PROD NO. 8292708, WASTEHANDLER
PROD NO. 8292709, DEMOLITION
PROD NO. 8301345, S/N 270789-, 280692-, 231204-
PROD NO. 8301346, S/N 270789-, 280692-, 231204-
CAB
PROD NO. 8290413
PROD NO. 8290414
PROD NO. 8290415
PROD NO. 8290416
PROD NO. 8291311
PROD NO. 8293085
PROD NO. 8293086
PROD NO. 8293087
PROD NO. 8293088
PROD NO. 8293089
PROD NO. 8293090
PROD NO. 8293091
PROD NO. 8293092
PROD NO. 8299644
PROD NO. 8301691
ENGINE
PART NO. 15165690, D6H part not stocked as spare part
PART NO. 17231272 replacement version
PART NO. 15083723, D6H part not stocked as spare part
PART NO. 17231270 replacement version
PART NO. 17216591, D6 part not stocked as spare part
PART NO. 14536076 replacement version
PART NO. 14536073, D6
Part NO. VOE15800373 for Volvo EC220E(S/N 310001-, 320001-)
EXCAVATOR VOLVO EC220E
BASIC MACHINE
Product number 8294862, Serial number 310001-, 320001-
CAB
Product number 8292998
Product number 8294134
Product number 8295278
Product number 8295279
Product number 8295391
Product number 8297179
Product number 8298509
Product number 8300787
Product number 8300788
Product number 8300789
Product number 8300790
Product number 8300791
Product number 8300861
ENGINE
Replacement version 17211944
Replacement version 17211945
Replacement version 17480996, D6J T4F
Replacement version 17507005, D6J T4F
Replacement version 17668815, D6 STG V
Part NO. VOE15800373 for Volvo EC380EHR(S/N 390001-)
EXCAVATOR VOLVO EC380EHR
BASIC MACHINE
Product number 8296946, Serial number 390001-
CAB
Product number 8297057
Product number 8297058
ENGINE
Product number 15185568
Replacement version 17272079
Product number 15185569
Replacement version 17272080
Product number 17481129
Replacement version 17481323
Product no. 17479201
Replacement version 17510356
Product no. 17479200
Replacement version 17510359
Part NO. VOE15800373 for Volvo EC300D(S/N 21/23/231001-/25/ 26/27/28000-)
EXCAVATOR VOLVO EC300D
BASIC MACHINE
PROD NO. 8289044, S/N 210001-211176, 230001-230373, 231001-, 250001-, 260001-260064, 270001-, 280001-
SUB BASIC MACHINE
PROD NO. 8292889 Waste handler, S/N 210044-
PROD NO. 8292890 Demolition, S/N 210068-
PROD NO. 8291941, S/N 210525-
PROD NO. 8292870, S/N 230001-230373, 231001-, 250001-, 260001-260064, 270001-, 280001-
PROD NO. 8301347, S/N 270875-, 280197-, 231394-
PROD NO. 8301348, S/N 270875-, 280197-, 231394-
CAB
PART NO. 11294093
PART NO. 11294094
PROD NO. 8293085
PROD NO. 8293086
PROD NO. 8293087
PROD NO. 8293088
PROD NO. 8293089
PROD NO. 8293090
PROD NO. 8293091
PROD NO. 8293092
PROD NO. 8299644
ENGINE
PROD NO 15165693
Replacement version 17231262
PROD NO 15083725
Replacement version 17231261
PROD NO 17213165
PROD NO 17213168
Part NO. VOE15800373 for Volvo EC250D(S/N 210/220/230/231/ 240/245/260/270/280)
EXCAVATOR VOLVO EC250D
BASIC MACHINE
PROD NO. 8289309, S/N 210001- 210459, 220001- 220774, 230001-230434, 231001-, 240001-, 245001-, 260001-260111, 270001-, 280001-
SUB BASIC MACHINE
PROD NO. 8291306 Waste handler S/N 210030-
PROD NO. 8291144 Demolition S/N 210040-
PROD NO. 8291305 S/N 210525-
PROD NO. 8293156 S/N 230001-, 231001-, 240001-, 245001-, 260001-260111, 270001-, 280001-
PROD NO. 8301347 S/N 270875-, 280197-, 231394-
PROD NO. 8301348 S/N 270875-, 280197-, 231394-
CAB
PART NO. 11294093
PART NO. 11294094
PROD NO. 8293085
PROD NO. 8293086
PROD NO. 8293087
PROD NO. 8293088
PROD NO. 8293089
PROD NO. 8293090
PROD NO. 8293091
PROD NO. 8293092
PROD NO. 8299644
ENGINE
PART NO. 15165691
part not stocked as spare part
PART NO. 15083724
part not stocked as spare part
PART NO. 17239320
PART NO. 17213164
Part NO. VOE15800373 for Volvo EC480EHR(S/N 390001-)
EXCAVATOR VOLVO EC480EHR
BASIC MACHINE
Product number 8297366, Serial number 390001-
CAB
Product number 8297057
Product number 8297058
ENGINE
Product number 15185568
Replacement version 17272079
Product number 15185569
Replacement version 17272080
Product number 17481129
Replacement version 17481323
Product no. 17479201
Replacement version 17510356
Product no. 17479200
Replacement version 17510359
