Volvo VOE14882083 Xtraflex/5000 aftermarket part for sale

Part Name: VOE14882083 Hose assembly

KDSORT: 320

UE: U

ANT1: 1

Hose Recipe Asmoverall Length MM: 730

Hose Recipe Asmoverall Length Inch: 28.74

Hose Recipe Asmoverall Length ToL MM: +/- 1%

Hose Recipe Asmoverall Length ToL inch: +/- 1%

Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees

Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)

Hose Recipe Safety Standard: EN 982-1996

Hose Recipe Assembly Instruction Reference: 1076838

Hose Recipe Version: 2

Hose Recipe Status: A

Hose Recipe Vendor: MANULI

Hose Recipe Grade: 1

Hose Part Hose Description: Xtraflex/5000

Hose Part Hose Size DN: 25

Hose Part Hose Size Inch: 1"

Hose Part Hose Dash: -16

Hose Part Hose Pressure Class MPA: 35.0

Hose Part Hose Pressure Class PSI: 5075

Hose Part Hose Pressure Class BAR: 350

Hose Part Hose Standard ISO: ISO 18752-C

Hose Part Hose Standard SAE: Volvo 106

Hose Part Hose Standard EN: Volvo 106

Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1

Hose Part Hose Structure: Wire spiralled four layer

Hose Part Hose Remark: Extreme flexibility

Hose Part Hose Outer Diameter MM: 39

Hose Part Hose Outer Diameter INCH: 1.54

Hose Part Cancelled: N

Hose Part Vendor: MANULI

Hose Part Grade: 1

Hose Part In Program: Y

Catalog: 20255/916/2000

Looking for Part NO.VOE14882083?
We offer ISUZU / Hitachi / Kubota / Deutz / Doosan / Kobelco aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.

We offer Komatsu / Hitachi / SUMITOMO / Deutz / Kubota / MITSUBISHI spare parts. MOQ 1 pcs is available! Volvo Part NO.VOE14882083 is on sale now!

Part NO. VOE14882083 for Volvo ECR305C(S/N 110001-)

This catalogue lists the spare parts for Excavator ECR305C.

BASIC MACHINE

PROD NO 8285324, ECR305C, SER NR ; 110001 -

ENGINE

Part no. : 14575315, D7E EAE3 Emission-Certified from EPA/EU
