SA9453-02608 Hose assembly for Volvo Excavator Parts

SA9453-02608 Hose assembly for Volvo Excavator Parts

volvo-sa9453-02608-for-sale

View

View

SA9453-02608 Hose assembly for Volvo Excavator Parts

Interview

Select the number of specifications

Please check the product information you want!

Product Detail

Volvo EW170 & EW180(SER NO 3031-) excavator spare part SA9453-02608 Eternity/2

Part Name: SA9453-02608 Hose assembly
KDSORT: 310, 250
UE: U
ANT1: 1
ANT2: 1
GLB_ANM1: SER NO 12317-, SER NO 3031-3036
Hose Recipe Asmoverall Length MM: 400
Hose Recipe Asmoverall Length Inch: 15.75
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 3 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Eternity/2
Hose Part Hose Size DN: 6
Hose Part Hose Size Inch: 1/4"
Hose Part Hose Dash: -04
Hose Part Hose Pressure Class MPA: 45.0
Hose Part Hose Pressure Class PSI: 6525
Hose Part Hose Pressure Class BAR: 450
Hose Part Hose Standard ISO: ISO 11237 2SC
Hose Part Hose Standard SAE: SAE 100R16
Hose Part Hose Standard EN: EN 857 2SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: High service life and reliability
Hose Part Hose Outer Diameter MM: 14
Hose Part Hose Outer Diameter INCH: 0.55
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20016/911/5100, 56125/924/200
Looking for Part NO.SA9453-02608?
We supply Hitachi / SUMITOMO / Deutz / YANMAR / SAMSUNG / ISUZU spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
SA9453-02608 for Volvo Quickfit and rotator hydraulic(SJ328 assembly)
Volvo SA9453-02608 Hose assembly suitable for SJ328 Quickfit and rotator hydraulic assembly.
Volvo SA9453-02608(c.SJ328) Eternity/2
Ref: SJ328 / 14 / 1
SAEK20B001 / U Hydr. Quick fit equipment on basic machine
SAEK18B001 / U Leak-off line for slope-rotator on basic machine
56125/924/200
SA9453-02608 for Volvo Hydraulic system, control valve to return filter(1029166 assembly)
Volvo SA9453-02608 Eternity/2 suitable for 1029166 Hydraulic system, control valve to return filter assembly.
Volvo SA9453-02608(c.1029166) Eternity/2
Ref: 1029166 / / 2
VOE8278981 / U / EC210B Forestry Kit with High Walker for Russia
VOE8279092 / U / EC210B Forestry Kit without High Walker for Russia
20016/911/5100
Heavy machine parts offer MITSUBISHI / SUMITOMO / Komatsu / Kubota / Hitachi / Deutz aftermarket parts. MOQ 1 pcs is available! Volvo Part NO.SA9453-02608 is on sale now!
Part NO. SA9453-02608 for Volvo EC210B(APPENDIX FORESTRY VERSION)
This catalogue lists the spare parts for Excavator EC210B.
BASIC MACHINE
PROD NO 8277784, EC210B, KOR S/N 23001 - 25067
PROD NO 8277784, EC210B, CHN S/N 30001 - 34952
PROD NO 8277784, EC210B, KOR S/N 10001 - 19999
PROD NO 8277784, EC210B, KONZ S/N 20001- 20837
ENGINE
Part No. 14500388, D6D EAE2. S/N 10001-11533
Part No. 14500388, D6D EAE2, KOR S/N 11534- / CHN S/N 30014-
Emission Certificated from EPA
Part No. 14519203, D6D EFE2, KOR S/N 11534- / CHN S/N 30014-
Emission Certificated from EU
Part No. 14519204, D6D EGE2, KOR S/N 11534- / CHN S/N 30014-
Without label
Part NO. SA9453-02608 for Volvo EW170 & EW180(SER NO 3031-)
This catalogue lists the spare parts for Excavator EW170/EW180.
BUCKETS
Bucket GP. ESCO. 0,71/0,75 - F24.
Description:
GP = General purpose. RB= Rock bucket.
ESCO = Type of bucket tooth, Esco.
0,71 = Volume CECE cubic meter.
0,75 = Volume SAE cubic meter.
S1 = Quick fit bucket.
F24 = Direct-mounted pin-on bucket.
We have our own production/R&D factory, high quality and low price are our advantages.
With more than 10 years of machinery industry experience, we have received praise from all over the world (customer / reseller / manufacturers / distributors).
Original SA9453-02608 included regular invoice.
Used/Second hand SA9453-02608 provide 3-12 months quality guarantee .
All Taxes included, no more hidden fee.
Choose us, get permanent online support, our Golden Engineers are ready.
