Wholesale SA9453-02252 Pilot for Volvo Excavator

Part Name: SA9453-02252 Hose assembly

KDSORT: 180, 200, 300, 190, 8009, 330, 310, 160, 430

UE: U

ANT1: 1, 0000, 2

ANT2: 1, 0000, 2

ANT3: 1

GLB_ANM1: S/N 11515-12094, SER NO 4003-

GLB_ANM2: S/N 80001-80626

Hose Recipe Asmoverall Length MM: 2600

Hose Recipe Asmoverall Length Inch: 102.36

Hose Recipe Asmoverall Length ToL MM: +/- 1%

Hose Recipe Asmoverall Length ToL inch: +/- 1%

Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees

Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)

Hose Recipe Safety Standard: EN 982-1996

Hose Recipe Assembly Instruction Reference: 1076838

Hose Recipe Version: 1

Hose Recipe Status: A

Hose Recipe Vendor: MANULI

Hose Recipe Grade: 1

Hose Part Hose Description: Pilot

Hose Part Hose Size DN: 6

Hose Part Hose Size Inch: 1/4"

Hose Part Hose Dash: -04

Hose Part Hose Pressure Class MPA: 15.0

Hose Part Hose Pressure Class PSI: 2175

Hose Part Hose Pressure Class BAR: 150

Hose Part Hose Standard ISO: Volvo 100

Hose Part Hose Standard SAE: Volvo 100

Hose Part Hose Standard EN: Volvo 100

Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1

Hose Part Hose Structure: Wire braided one layer

Hose Part Hose Remark: Extreme lightness

Hose Part Hose Outer Diameter MM: 12

Hose Part Hose Outer Diameter INCH: 0.47

Hose Part Cancelled: N

Hose Part Vendor: MANULI

Hose Part Grade: 1

Hose Part In Program: Y

Catalog: 20072/914/2200, 20490/914/2800, 20079/914/310, 56117/916/400, 20461/914/200, 20487/914/2200, 20461/914/250, 20490/914/200, 56142/914/200, 56117/443/300, 20080/914/200, 56142/914/2500, 20870/911/450, 20431/914/2500

Looking for Part NO.SA9453-02252?
We supply HYUNDAI / Doosan / SUMITOMO / MITSUBISHI / KATO / CASE spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.

We offer SAMSUNG / Komatsu / Kobelco / SUMITOMO / ISUZU / CUMMINS aftermarket parts. MOQ 1 pcs is available! Volvo Part NO.SA9453-02252 is on sale now!

Part SA9453-02252 suitable for:


VOE8279206 / U / PLUS PARTS FOR SINGLE ACTING Hydr. leak-off line for hammer-shear.

VOE8277787 / P / EC140B Basic Machine

VOE8286047(VOE14602683) / U / DOUBLE ACTING Hydr. leak-off line for hammer-shear. 2 pump

VOE8301962 / U Lower frame, welded step

VOE8300611 / U Lower frame, welded step

VOE8279625 / P / EC240B Basic Machine

Part NO. SA9453-02252 for Volvo EC140B(PRIME S/N 15001-, 30001-30121, 40001-)

This catalogue lists the spare parts for Excavator EC140B.

BASIC MACHINE

PROD NO 8277787, EC140B, S/N 15001-, 30001-30121, 40001-40976

ENGINE

Part No. 14521396, D4D EAE2, Emission Certificated from EPA

Part No. 14521397, D4D EBE2, Emission Certificated from EU

Part No. 14521398, D4D ECE2, Without label

Part NO. SA9453-02252 for Volvo EC200D(S/N 280001-)

EXCAVATOR VOLVO EC200D

BASIC MACHINE

Product number 8297134, Serial number 240001-, 280001-

SUB BASIC MACHINE

Product number 8300596, Serial number 240001-, 280001-

CAB

Product number 8296864

Product number 8300602

Product number 8300603

ENGINE

PART NO. 17387726, D5 T3

Part NO. SA9453-02252 for Volvo EC135B(SER NO 20001-20079)

This catalogue lists the spare parts for Excavator EC135B.

BASIC MACHINE

PROD NO 8277787, EC135B, SER NO 20001-

ENGINE

Part No. 14521397, D4D EAE2, Emission Certificated from EU

Part NO. SA9453-02252 for Volvo EC140B

This catalogue lists the spare parts for Excavator EC140B.

BASIC MACHINE

PROD NO 8277787, EC140B, KOR S/N 10001- 13506

PROD NO 8277787, EC140B, KONZ S/N 20001- 21230

ENGINE

Part No. 14500389, D4D EAE1, SER NO 10001-10705

Part No. 14500389, D4D EAE1, SER NO 10706-10945

Part No. 14521396, D4D EAE2, SER NO 10946-

Emission Certificated from EPA

Part No. 14519205, D4D EBE1, SER NO 10706-10945

Part No. 14521397, D4D EAE2, SER NO 10946-

Emission Certificated from EU

Part No. 14519206, D4D ECE1, SER NO 10706-10945

Part No. 14521398, D4D ECE2, SER NO 10946-

Without label

Part NO. SA9453-02252 for Volvo EC460B(PRIME)

This catalog lists the spare parts for Excavator EC460B

BASIC MACHINE

PROD NO 8277120, EC460B, S/N 15001 - 18400 KOR

PROD NO 8277120, EC460B, S/N 85001 - 85201 KOR T3

ENGINE

Part No. 8188757, D12D-P, S/N 85001 - , 8288737,

Emission Certificated from EPA and EU

Part No. 8188747, D12D-O, S/N 15001 - , 8288735

Part NO. SA9453-02252 for Volvo EW145B(PRIME S/N 15001-)

This catalogue lists the spare parts for Excavator EW145B

BASIC MACHINE

PROD NO 8279320, EW145B, SER NO ; 15001 -

SUB BASIC MACHINE

PROD NO 8287683, EW145B, SER NO ; 15001 -

ENGINE

Part No. 14533107, D6E EIE3 Emission Certified from EPA/EU, SER NO ; 15001 - 17163

Part No. 17216587, D6E EIE3 Emission Certified from EPA/EU, SER NO ; 17164 -
