Volvo excavator part VOE937417 Hose assembly for sale

Part Name: VOE937417 Hose assembly

KDSORT: 580, 140, 100, 500, 820, 300, 510, 180, 150

UE: U

ANT1: 1, 0000

ANT2: 1

GLB_ANM1: S/N 280157-

Hose Recipe Asmoverall Length MM: 2500

Hose Recipe Asmoverall Length Inch: 98.43

Hose Recipe Asmoverall Length ToL MM: +/- 1%

Hose Recipe Asmoverall Length ToL inch: +/- 1%

Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees

Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)

Hose Recipe Safety Standard: EN 982-1996

Hose Recipe Assembly Instruction Reference: 1076838

Hose Recipe Version: 1

Hose Recipe Status: A

Hose Recipe Vendor: MANULI

Hose Recipe Grade: 1

Hose Part Hose Description: Rockmaster/1SC

Hose Part Hose Size DN: 12

Hose Part Hose Size Inch: 1/2"

Hose Part Hose Dash: -08

Hose Part Hose Pressure Class MPA: 19.0

Hose Part Hose Pressure Class PSI: 2755

Hose Part Hose Pressure Class BAR: 190

Hose Part Hose Standard ISO: ISO 11237

Hose Part Hose Standard SAE: Volvo 101

Hose Part Hose Standard EN: EN 857 1SC

Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1

Hose Part Hose Structure: Wire braided one layer

Hose Part Hose Remark: Abrasion, weather and heat resistance

Hose Part Hose Outer Diameter MM: 20

Hose Part Hose Outer Diameter INCH: 0.79

Hose Part Cancelled: N

Hose Part Vendor: MANULI

Hose Part Grade: 1

Hose Part In Program: Y

Catalog: 20137/914/290, 20864/911/450, 20098/914/300, 20743/645/200, 20668/914/310, 20744/911/450, 20706/911/650, 20099/914/300, 20136/914/290, 20668/914/300

Looking for Part NO.VOE937417?
We offer Hitachi / ISUZU / Kubota / HYUNDAI / KATO / SAMSUNG spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.

We supply Hitachi / Doosan / CASE / Deutz / SUMITOMO / CUMMINS aftermarket parts. MOQ 1 pcs is available! VOLVO Part NO.VOE937417 is on sale now!

Part VOE937417 suitable for:


VOE8291986 / P / EC80D Basic Machine

VOE8291991 / U / AUTO DECELERATION Engine acceleration control

VOE8299408 / U / T2, POCLAIN Swing motor

VOE8291991 / U / AUTO DECELERATION Engine acceleration control

VOE8291986 / P / EC80D Basic Machine

VOE8296212 / U / WITHOUT SLOPE/ROTATOR PIPING Without Leak-off line for slope-rotator

VOE8287584 / P / EC240C Basic Machine

Part NO. VOE937417 for Volvo EWR150E(S/N 320011, 322001-)

EXCAVATOR VOLVO EWR150E

BASIC MACHINE

Product number 8295710, Serial number 320011-321068, 322001-

Product number 8300994, Serial number 322001-

CAB

Product number 8295937

Product number 8295938

Product number 8295939

Product number 8295940

DRIVE AXLES

Part number 14693935, front

Part number 14693936, front

Part number 14590302, rear

Part number 14590304, rear

TRANSMISSION

Part number 14645851

Part number 14645852

ENGINE

Product number 17229254, D4J T4F

Product number 17229251, D4J T4F

Product number 17506997, D4J T4F

Product number 17668808, D4 STAGE V

Part NO. VOE937417 for Volvo EW205D(S/N 280001-)

EXCAVATOR VOLVO EW205D

BASIC MACHINE

PROD NO. 8293360, S/N 280001-

CAB

PROD NO. 8293019

PROD NO. 8293020

PROD NO. 8295149

PROD NO. 8295150

ENGINE

PART NO. 17239340

Part NO. VOE937417 for Volvo EC240C

This catalogue lists the spare parts for Excavator EC240C.

BASIC MACHINE

PROD NO 8281075, EC240C, KOR SER NO ; 110001 - 111049

PROD NO 8281075, EC240C, KONZ SER NO ; 120001 - 120675

PROD NO 8281075, EC240C, USA SER NO ; 140001 - 140019

ENGINE

Part No. : 14527731, D7E EBE3 Emission Certified from EPA/EU

Part NO. VOE937417 for Volvo FC2924C(S/N 110001 - 110040)

This catalogue lists the spare parts for Excavator FC2924C.

BASIC MACHINE

PROD NO 8284166, FC2924C, SER NO ; 110001 - 110040

ENGINE

Part No. : 14527731, D7E EBE3 Emission-certified from EPA/EU

Part NO. VOE937417 for Volvo EWR170E(S/N 320011-)

EXCAVATOR VOLVO EWR170E

BASIC MACHINE

Product number 8301029, 8300994, Serial number 320011-

CAB

Product number 8295279

Product number 8292998

Product number 8294134

Product number 8295278

DRIVE AXLES

Part number 14693936, front

Part number 14693937, front

Part number 14590304, rear

Part number 14590306, rear

TRANSMISSION

Part number 14645850

ENGINE

Part number 17483700, D4J T4F

Part number 17483701, D4J T4F

Part number 17506995, D4J T4F

Part number 17668807, D4 STAGE V

Part NO. VOE937417 for Volvo EC290C(S/N 110001 - 111856)

This catalogue lists the spare parts for Excavator EC290C

BASIC MACHINE

PROD NO 8280940, EC290C, SER NO ; 110001 - 111856

ENGINE

Part No. 14527732, D7E Emission Certified from EPA/EU
